Heavy-Duty Steel Cf Training Frame

The Heavy duty steel CF training frame is a multifunctional training stand designed specifically for CrossFit, strength training, and functional training. It is made of high-strength steel (such as Q345B or ASTM A500) and features high load-bearing capacity, high stability, and modular design. Its core functions include pull-up, barbell squat, bench press, hard pull, rope training, etc. It is widely used in gyms, fitness training centers, and professional sports teams.

Function: multi-function training fitness cf frame

Applicable: General

Materials: steel pipe

Logo: Customizable

Size: Customizable

Color: Customizable

Service: OEM support

2、 Core Features

1. High strength steel and load-bearing capacity

Material: Q345B low-alloy high-strength steel (yield strength ≥ 345MPa) or ASTM A500 structural steel pipe with a wall thickness ≥ 3mm is used.

bearing:

Horizontal bar load-bearing capacity: ≥ 500kg (dynamic load test passed 1000 cycles)

Hanging piece load-bearing capacity: ≥ 300kg/side (equipped with J-shaped hook, anti slip design)

Overall structural load-bearing capacity: ≥ 1500kg (static load test)

Data basis: Complies with the international fitness equipment standard EN 957-1 and has been certified by a third-party laboratory.

2. Modular design and scalability

Components:

Basic framework: 2.2m (height) x 1.2m (width) x 1.8m (depth), column spacing of 90cm

Optional accessories: Pull up rod (diameter 33mm, surface anti slip treatment), dumbbell rack (10 positions), storage basket (load-bearing 50kg)

Scalability:

Connector: Made of M12 high-strength bolts, can be spliced into double or multiple rows of training areas

Attachment compatibility: Supports CrossFit standard attachments (such as elastic band anchor points, climbing rope brackets)

3. Ergonomics and Safety

Horizontal bar height:

Lowest point: 60cm (suitable for hard pull training)

Highest point: 2.2m (meets pull up and Olympic weightlifting needs)

Safety design:

Anti slip foot pad: diameter 10cm, rubber material (Shore hardness 70 ± 5HA)

Anti collision corner protector: made of polyurethane material, with an impact strength of ≥ 50J/cm ²

Emergency stop device: The rope training area is equipped with an electromagnetic brake system (response time ≤ 0.2 seconds)

4. Surface treatment and durability

workmanship

Acid pickling and phosphating treatment (rust removal grade Sa2.5)

Electrostatic spraying (thickness 80-120 μ m, adhesion level 0)

Corrosion resistance:

Salt spray test: 720 hours without red rust (ASTM B117 standard)

Wear resistance: Taber wear resistance test (CS-10 wheel, 500g load) ≤ 50mg loss

5. Space utilization and layout flexibility

area covered:

Unit: 2.16 ㎡ (2.2m × 0.98m, including safety distance)

Double row layout: 4.32 square meters (with a spacing of 1.2m, suitable for multiple people training simultaneously)

Application scenarios:

Commercial fitness center: 4-6 groups can be configured per 100 square meters to accommodate 50 people per hour

Family training room: minimum space requirement 3m x 3m

3、 Application Fields

1. Commercial fitness center

Requirement: High intensity, low maintenance cost, optimized membership experience

case

Chain gym purchases 10 sets, increases membership renewal rate by 12% within 6 months

Daily average usage of a single device: 80-120 times

2. Professional sports teams

Requirement: Accurate training data, customized configuration

case

National Weightlifting Team Training Base: Equipped with force sensors (accuracy ± 1%), real-time monitoring of training load

Rope Training Module: Resistance Adjustment Range 5-100kg (0.5kg increments)

3. Military physical training

Requirement: Extreme environment adaptability, rapid deployment

case

Marine Corps Training Camp: Adopting a foldable design (with a folded volume of 0.8m ³)

Desert environment testing: Surface temperature tolerance range -40 ℃ to+60 ℃

4. Enterprise Health Management

Requirement: Support for group courses and increase employee participation

case

Technology company: introduces' daily challenge 'mode, average employee BMI drops by 1.2kg/m ²

Supporting APP: Record training data and generate personalized reports
